Front bumper cover removal

Hey guys...I want to pull the headlight housings out (for a mod) and I need to get the front bumper cover off first.

Anyone take the front bumper cover off yet or know how to do it otherwise? I can figure it out, but if someone knows the process, it would speed things up greatly and keep me from having to poke and pry and risk popping clips.

Thanks in advance!
__________________

__________________
Reply With Quote
  #2
Old 02-11-2011, 06:46 PM
pattyboy's Avatar
Premium Member
My Jeep: 2011 3.6L WK2

Join Date: Sep 2010
Location: middle village n.y.
Posts: 266
Thanks: 10
Thanked 1 Time in 1 Post
Rep Power: 1789
pattyboy is a glorious beacon of light
Re: Front bumper cover removal

wk or wk2?????????there r post, do a search for wks ,its been posted before.........i be doing wk2 tommorrow/////////////pattyboy
__________________

__________________
Reply With Quote
  #3
Old 02-11-2011, 07:04 PM
Member

Join Date: Jan 2011
Posts: 183
Thanks: 0
Thanked 2 Times in 1 Post
Rep Power: 1599
pbalias has a reputation beyond reputepbalias has a reputation beyond reputepbalias has a reputation beyond repute
Re: Front bumper cover removal

WK2. I searched and didn't find anything. You're taking the bumper off your WK2 tomorrow? If so...PLEASE take pics! I need to do it asap.
__________________
Reply With Quote
  #4
Old 02-11-2011, 07:12 PM
pattyboy's Avatar
Premium Member
My Jeep: 2011 3.6L WK2

Join Date: Sep 2010
Location: middle village n.y.
Posts: 266
Thanks: 10
Thanked 1 Time in 1 Post
Rep Power: 1789
pattyboy is a glorious beacon of light
Re: Front bumper cover removal

Nothing posted 4 wk2 only wk why do u need to remove ,i am installing summit grille
__________________
Reply With Quote
  #5
Old 02-11-2011, 07:22 PM
Member

Join Date: Jan 2011
Posts: 183
Thanks: 0
Thanked 2 Times in 1 Post
Rep Power: 1599
pbalias has a reputation beyond reputepbalias has a reputation beyond reputepbalias has a reputation beyond repute
Re: Front bumper cover removal

I want to remove the headlights. Bumper has to come off first though. PLEASE let me know how you take that bumper off tomorrow. THANKS MAN!!!
__________________
Reply With Quote
  #6
Old 02-11-2011, 07:25 PM
pattyboy's Avatar
Premium Member
My Jeep: 2011 3.6L WK2

Join Date: Sep 2010
Location: middle village n.y.
Posts: 266
Thanks: 10
Thanked 1 Time in 1 Post
Rep Power: 1789
pattyboy is a glorious beacon of light
Re: Front bumper cover removal

I know for sure u must remove the removable lower fascia 4 sure....but i will inform u as soon as i complete may be Sunday i was just informed by the boss!!!!
__________________
Reply With Quote
  #7
Old 02-11-2011, 07:30 PM
Scottina06's Avatar
JeepGarage Founder
My Jeep: 2014 6.4L SRT8 WK2

Join Date: May 2009
Location: Berea, Kentucky
Posts: 49,381
Thanks: 875
Thanked 1,046 Times in 721 Posts
Rep Power: 7718298
Scottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond repute
Garage
Re: Front bumper cover removal

are the fender liners held on with plastic rivets?
__________________
SCOTT
The HARDER you work...the LUCKIER you are!
2014 REDLINE red Jeep SRT "BLOODIED\BlackOps CFR Edition" 1 of 1
2013 JKU Wrangler 10A-stormtrooper'ed, JW Speaker and more!
Previous JEEP rides-
2013 Jeep Grand Cherokee SRT-deep cherry
2006 Jeep Grand Cherokee Laredo-inferno red



Twitter-The_Jeep_Guy
Instagram-thejeep_guy

Reply With Quote
  #8
Old 02-11-2011, 07:54 PM
Member

Join Date: Jan 2011
Posts: 183
Thanks: 0
Thanked 2 Times in 1 Post
Rep Power: 1599
pbalias has a reputation beyond reputepbalias has a reputation beyond reputepbalias has a reputation beyond repute
Re: Front bumper cover removal

From initial inspection:

- There is a 10MM screw/bolt in the upper-most corner of the bumper cover, in each wheel well, where the tip of the bumper cover meets the edge of the fender.

- The plastic fender "flare" extends into the bumper cover, where it is secured by non-reusable plastic rivets. The rest of the fender flare is fastened to the fender via push-in snaps. These are heavy duty snaps and in my professional experience, they often break when pulling them out.

- The grille is attached to the top of the bumper cover via tabs. The tabs are not accessible. The grille comes off with the bumper. The top of the grille snaps (very snugly) via 4 clips into the top of the radiator support.

- The bottom rear of the bumper cover is attached to the lower splash shield/engine cover via plastic push-pin 2-peice (reusable) expansion clips.

- It *appears* there are bumper cover retainers just under the headlights that grab the lip of the bumper cover.

How I *think* this needs to happen:

- The 10MM screws (1 on each side) need to be removed.

- The grille needs to be popped up off the radiator support

- Release the lower splash shield from the bumper

- Once the fender liners are removed, you should be able to get a better idea of the any more bumper cover mounting points.

- The fog lights get disconnected

- If there are no other mounting points, the bumper gets popped forward to release the grasp of the upper retainers and slides free.

HOPEFULLY that does it. Just be very careful. I haven't taken the bumper off yet so I don't know if there are any other mounting points. I'm going to poke around it again tomorrow to see what else I can come up with.

From there, the headlight housings are secured to the radiator support via at least 3 10MM bolts, one on top and 2 underneath. Once the wiring is disconnected from the light housings, the housings should come free.
__________________
Reply With Quote
  #9
Old 02-11-2011, 08:18 PM
Scottina06's Avatar
JeepGarage Founder
My Jeep: 2014 6.4L SRT8 WK2

Join Date: May 2009
Location: Berea, Kentucky
Posts: 49,381
Thanks: 875
Thanked 1,046 Times in 721 Posts
Rep Power: 7718298
Scottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond repute
Garage
Re: Front bumper cover removal

heres the grill...front and back.


I dont see anywhere on the bottom for any kind of retainer clip/fastener. Its looks to be similar to the WK. The WK's grill on the bottom...snaps into the bumper support bracket.
__________________
SCOTT
The HARDER you work...the LUCKIER you are!
2014 REDLINE red Jeep SRT "BLOODIED\BlackOps CFR Edition" 1 of 1
2013 JKU Wrangler 10A-stormtrooper'ed, JW Speaker and more!
Previous JEEP rides-
2013 Jeep Grand Cherokee SRT-deep cherry
2006 Jeep Grand Cherokee Laredo-inferno red



Twitter-The_Jeep_Guy
Instagram-thejeep_guy

Reply With Quote
  #10
Old 02-11-2011, 08:39 PM
Member

Join Date: Jan 2011
Posts: 183
Thanks: 0
Thanked 2 Times in 1 Post
Rep Power: 1599
pbalias has a reputation beyond reputepbalias has a reputation beyond reputepbalias has a reputation beyond repute
Re: Front bumper cover removal

cool, thanks scott. What are you doing with that grille? where you able to remove/install it without removing the front bumper cover? Or is that a spare or something?
__________________
Reply With Quote
  #11
Old 02-11-2011, 09:12 PM
Scottina06's Avatar
JeepGarage Founder
My Jeep: 2014 6.4L SRT8 WK2

Join Date: May 2009
Location: Berea, Kentucky
Posts: 49,381
Thanks: 875
Thanked 1,046 Times in 721 Posts
Rep Power: 7718298
Scottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond reputeScottina06 has a reputation beyond repute
Garage
Pattyboy and I were talking about removing the 2011's grill last night and I pulled these pics from off-line
Sent from my PC36100 using Tapatalk
__________________
SCOTT
The HARDER you work...the LUCKIER you are!
2014 REDLINE red Jeep SRT "BLOODIED\BlackOps CFR Edition" 1 of 1
2013 JKU Wrangler 10A-stormtrooper'ed, JW Speaker and more!
Previous JEEP rides-
2013 Jeep Grand Cherokee SRT-deep cherry
2006 Jeep Grand Cherokee Laredo-inferno red



Twitter-The_Jeep_Guy
Instagram-thejeep_guy

Reply With Quote
  #12
Old 02-12-2011, 10:14 AM
pattyboy's Avatar
Premium Member
My Jeep: 2011 3.6L WK2

Join Date: Sep 2010
Location: middle village n.y.
Posts: 266
Thanks: 10
Thanked 1 Time in 1 Post
Rep Power: 1789
pattyboy is a glorious beacon of light
Re: Front bumper cover removal

front bumper cover definitely needs to be removed for grille removal as well as head light into it about 45 Min's and its off installing grille .,.,,,,,,,just in to warm up a bit will give details later pattyboy
